LP3 - Ultra-fast Kalpha X Ray source
K alpha X-ray secondary source induced by laser-produced plasma for phase contast imaging and materials analysis
Laser-based light source parameters
Mo K alpha X ray
Source type
K_alpha
Peak Photon energy / central wavelenght
17400 [eV]
Beam shape
Other...
Pulse duration FWHM
1 [ps]
Polarisation
Unpolarized
Pulse repetition rate
100 [Hz]
Maximum pulse energy
2 * 10-6 [mJ]
Source size (spot)
X = 5 [um], Y = 6 [um]
Additional Lightsources
Ti:Sa pump
Laser type
Ti:Sa
Central Wavelength/Energy
800 [nm]
Wavelength fluctuations
1 [%]
Spectral Bandwidth FWHM
750 - 850 [nm]
Tunability
50 [%]
Beam shape
Gaussian
Pulse duration FWHM
25 [fs]
Pulse repetition rate
100 [Hz]
Maximum pulse energy
10 [mJ]
Peak power
4 * 1011 [W]
Techniques
Diffraction
- Surface diffraction
- Time-resolved studies
Imaging
- Medical application
Disciplines
Engineering & Technology
- Other - Engineering & Technology
Life Sciences & Biotech
- Medicine
- Other - Life Sciences & Biotech
Material Sciences
- Other - Material Sciences
control/Data analysis
Control Software Type
- Labview
Data Output Type
- -
Data Output Format
- -
